The YD-Z300A RFID Proximity Guard Tour System is a professional, reliable solution designed for high-efficiency patrol management. Built for field endurance, this lightweight reader replaces manual logs with automatic 125kHz RFID card sensing, eliminating traditional data gaps and ensuring precise, tamper-proof tracking of guard performance.
Engineered for demanding conditions, the device features a rugged weatherproof housing that withstands extreme environments. It serves as both a patrol reader and a tactical flashlight with multiple lighting modes for low-visibility shifts. With dual-backup data protocols integrated into the drive-free management software, the YD-Z300A provides a complete, scientific overview of security operations-from routine check-ins to impact event recording-ensuring full operational integrity.
Core Features & Technical Advantages
High-Speed Drive-Free Data Transfer
The YD-Z300A utilizes a streamlined software architecture. Users simply unzip the package-no driver installation required-and connect via USB to generate automated compliance charts, identifying missed or delayed checkpoints instantly.
Comprehensive Impact Tracking
Beyond tracking checkpoints, the system automatically logs 32,000 unique impact events, providing supervisors with objective records of how equipment is handled in the field.
Versatile Tactical Illumination
The built-in LED system includes five lighting modes: Strong, Medium, Weak, SOS, and Strobe, assisting guards in navigating dark environments while maintaining patrol continuity.
Battery Endurance for High-Frequency Use
Powered by a 3.7V internal lithium battery, the device is optimized for high-volume operations, supporting approximately 40,000 reads on a single full charge cycle.
Technical Specifications
| Parameter | Specification |
| SKU | YD-Z300A |
| Product Category | RFID Guard Tour Reader |
| Housing Dimensions | 142 mm × 47 mm × 30 mm |
| Device Weight | 136 g |
| RFID Technology | 125kHz EM-ID Contactless Induction Reading |
| Reading Range | 3 - 5 cm |
| Storage Capacity | 80,000 Patrol Records / 32,000 Impact Records |
| Communication | USB Data Cable |
| Housing Material | Industrial-Grade Construction |
| Ingress Protection | IP67 (Water and Dust Resistant) |
| Battery | 3.7V Rechargeable Lithium-Ion Battery |
| Battery Endurance | Approx. 40,000 reads per full charge |
| Operating Temperature | -40°C to 85°C |
| Relative Humidity | 0% to 95% (Non-condensing) |
Target Applications & Installation Scenarios
Logistics & Warehousing
Secures expansive storage zones by providing verifiable records of guard coverage across high-traffic inventory areas.
Construction & Remote Sites
Withstands extreme environmental conditions (-40°C to 85°C) in remote industrial sites and outdoor construction perimeters.
Utility & Infrastructure Facilities
Monitors power substations, water treatment plants, and data centers with high-accuracy RFID proof-of-presence.
Frequently Asked Questions
Q1: Does this system require software installation on every patrol computer?
A: No. The YD-Z300A management software is drive-free and portable. It can be run directly after unzipping, making it easy to deploy on any management PC.
Q2: How does the impact logging feature work?
A: The device contains an internal sensor that automatically records instances of dropping or physical shock, storing up to 32,000 events to help supervisors maintain equipment health.
Q3: How many reads can I perform on a single charge?
A: Under normal operational conditions, the YD-Z300A supports approximately 40,000 RFID reads per full charge cycle, ensuring long-term deployment without frequent power maintenance.
