Definition and Overview
Ticket system flap turnstile gate is an intelligent device that combines ticketing system and channel management functions.Through the integration of mechanical and electronic technologies, automated and intelligent management of personnel entry and exit is achieved.
Core Functions and Features
Verification can be done in multiple modes,such as such as card swiping (IC card/ID card), QR code (electronic ticket/bracelet), biometric identification (fingerprint/face), etc. It can be seamlessly connected with the online ticket purchasing platform to achieve unattended management of "one person, one gate, one ticket and one certificate".
Triple anti-pinch protection
Integrates infrared anti-pinch, mechanical anti-pinch and current detection anti-collision technology. When the gate encounters an obstacle during the reset process, it will automatically stop or reset again after a delay to ensure pedestrian safety.
Illegal intrusion alarm
Through infrared sensors and logical judgment algorithms, the channel status is monitored in real time, and audible and visual alarms are triggered for abnormal behaviors such as tailgating and reverse passage, and event data is recorded.
Automatic ticket system flap turnstile gate opening when power is off
To meet the requirements of fire protection regulations, the gate wings automatically retract to open the passage when power is off; it automatically resets after power is restored to ensure rapid evacuation in emergency situations.
Remote control and data statistics
Support remote gate opening and closing, parameter setting (such as gate closing time, traffic mode) and real-time data query (such as passenger flow, traffic records) through the management computer.
Technical Specifications and Advantages
| Housing material | YD-R788P |
| Body Material | Constructed from 304 stainless steel or cold-rolled steel plates, offering rust resistance, durability, and aesthetic appeal. |
| Structural Design | Modular design for easy maintenance and upgrades, with a sleek and modern appearance. |
| Standard Dimensions | L1400mm × W300mm × H1020mm, with a passage width of 550mm-600mm, adaptable to various installation needs. |
| Power Supply | AC220±10% V/50HZ, driven by DC brushless motors for stable and reliable operation. |
| Operating Temperature | -10℃~70℃, suitable for different climatic conditions. |
Typical Application Scenarios
Transportation Hubs
Such as airports, subway stations, railway stations, and ferry terminals, facilitating passenger flow distribution and security management.
01
Tourist Attractions
Integrates with electronic ticketing systems to enhance visitor entry efficiency and optimize tourism experiences.
02
Office Buildings
Manages employee and visitor access, improving workplace security and management efficiency.
03
Commercial Venues
Controls pedestrian traffic in shopping malls and exhibition centers, preventing theft and unauthorized entry.
04
Educational Institutions
Manages access in student dormitories and libraries, ensuring orderly personnel management.
05
Packaging
